Chanle & Samlongda manufacture 100% new PU tube with following feature:
1. Flexibility of Polyurethane tubing is still good under very low temperature, good elasticity.
2. Pretty high intensity, abrasion resistant and long service life, Small bending radius.
3. Light weight, high grade of transparency, anti-corrosion on partly chemical material, New products have hydrolysis resistant on Ether based PU tube.
4. The working temperature -20 to +70 degree.
5. Inner Wall of PU tubing is very smooth for transport.
6. Hardness 95± 2A, 98± 2A
7. PU is environmental material, our PU tubes reach SGS standards!
8. Widely used in Pneumatic automation system, Air tools.
9. Pneumatic fittings, NPT /BSPT fittings, Swivel coupler, Miltom type quick coupler are all available on our polyurethane tube.
10.Size: OD4mm*ID2.5mm, OD6mm*ID4mm, OD8mm*ID5mm, OD10mm*ID6.5mm, OD12mm*ID8mm, OD14mm*ID10mm, OD16mm*ID12mm.
1. Flexibility of Polyurethane tubing is still good under very low temperature, good elasticity.
2. Pretty high intensity, abrasion resistant and long service life, Small bending radius.
3. Light weight, high grade of transparency, anti-corrosion on partly chemical material, New products have hydrolysis resistant on Ether based PU tube.
4. The working temperature -20 to +70 degree.
5. Inner Wall of PU tubing is very smooth for transport.
6. Hardness 95± 2A, 98± 2A
7. PU is environmental material, our PU tubes reach SGS standards!
8. Widely used in Pneumatic automation system, Air tools.
9. Pneumatic fittings, NPT /BSPT fittings, Swivel coupler, Miltom type quick coupler are all available on our polyurethane tube.
10.Size: OD4mm*ID2.5mm, OD6mm*ID4mm, OD8mm*ID5mm, OD10mm*ID6.5mm, OD12mm*ID8mm, OD14mm*ID10mm, OD16mm*ID12mm.
| Code | Size(mm) | Tolerances | Standard Length(m) | Working Pressure @ 23ºC | Burst Pressurre @ 23ºC | Min Bend Radii | |
| O.D | I.D | ||||||
| PU0425 | 4 | 2.5 | ±0.10 | 200 | 10 | 35 | 12 |
| PU0604 | 6 | 4 | ±0.10 | 200 | 10 | 35 | 15 |
| PU0805 | 8 | 5 | ±0.10 | 100 | 10 | 35 | 19 |
| PU0806 | 8 | 6 | ±0.10 | 100 | 8 | 30 | 19 |
| PU1065 | 10 | 6.5 | ±0.10 | 100 | 10 | 35 | 25 |
| PU1208 | 12 | 8 | ±0.10 | 100 | 10 | 35 | 38 |
| PU1410 | 14 | 10 | ±0.15 | 100 | 8 | 30 | 60 |
| PU1612 | 16 | 12 | ±0.15 | 100 | 7 | 25 | 70 |
| PU 1/4" | 6.35 | 4.57 | ±0.10 | 200 | 10 | 35 | 12 |
| PU 3/8" | 9.5 | 6.5 | ±0.10 | 100 | 10 | 35 | 25 |
| PU 1/2" | 12.7 | 9.5 | ±0.15 | 100 | 10 | 35 | 38 |
