Main Features:
1/ No-skive design eliminates the need to remove the hose cover before 2/ 2/ crimping
3/ MSHA accepted cover
4/ 3000 PSI constant working pressure in all sizes
5/ It is made from the latest nanmeter material, providing good resistance to oil,ozone,and high pulse performance.
Product Features:
Premium Hose(Fc500/H471)
Easier Installation-46% improvement in force-to-bend, ½ SAE minimum bend in sizes -12 thru -24 and 33% reduction in bend radius for SAE 100R13-32
Environmentally Friendly - Class 0 Cool Down Leakage per SAE J1176 when assembled with the 4S/6S Fitting Series.
Reduced Downtime- using hoses that exceed industry performance requirements
Engineered Hose Assembly System-Quick and easy assembly through a matching and mating hose assembly process: Reduces the time to produce a hose assembly through color coordinated identifiers on the hose,hose fittings and crimp tooling
More discount please contact me
Contact person:
Ms. Samansa
Product Application:
Hydraulic system service with petroleum and water-based fluids, for general industrial service. Petroleum and fire-resistant hydraulic fluids, fuel and lubricating oils, gasoline, water and other industrial fluids Logging, construction, mining and other off highway applications.
| Hoze size | Inside Diameter mm | Reinforcement Diameter mm | Outside Diameter mm | Working Pressure | Proof Pressure | Burst Pressure | Min.Bend Radius mm | Weight Kg/m | |||
| Mpa | Psi | Mpa | Psi | Mpa | Psi | ||||||
| 1-5-21 | 5±0.5 | 9.5±0.6 | 12.7±0.8 | 21 | 3043 | 31.5 | 4564 | 63 | 9129 | 90 | 0.25 |
| 1-6-20 | 6±0.5 | 11.3±0.6 | +1 | 21 | 3043 | 31.5 | 4564 | 63 | 9129 | 100 | 0.34 |
| 15.3-0.8 | |||||||||||
| 1-8-18 | 8±0.5 | 13.3±0.6 | +1 | 18 | 2536 | 27 | 3804 | 54 | 7607 | 115 | 0.41 |
| 17.3-0.8 | |||||||||||
| 1-10-6 | 10±0.5 | 15.3±0.6 | +1 | 16 | 2318 | 24 | 3478 | 48 | 6955 | 130 | 0.47 |
| 19.3-0.8 | |||||||||||
| 1-13-14 | 13±0.5 | 18.8±0.6 | +1.2 | 14 | 2028 | 21 | 3043 | 42 | 6086 | 180 | 0.67 |
| 22.8-0.8 | |||||||||||
| 1-16-12 | 16±0.5 | 21.8±0.8 | +1.2 | 12 | 1739 | 18 | 2608 | 36 | 5216 | 205 | 0.7 |
| 25.8-1 | |||||||||||
| 1-19-10 | 19±0.5 | 24.8±0.8 | +1.2 | 10 | 1449 | 15 | 2174 | 30 | 4347 | 240 | 0.84 |
| 28.8-1 | |||||||||||
| 1-22-9 | 22±0.5 | 27.8±0.8 | +1.2 | 9 | 1304 | 13.5 | 1956 | 27 | 3912 | 280 | 0.95 |
| 31.8-1 | |||||||||||
| 1-25-8 | 25±0.5 | 31.3±0.8 | +1.2 | 8 | 1159 | 12 | 17.9 | 24 | 3478 | 300 | 1.09 |
| 35.3-1 | |||||||||||
| 1-32-6 | 32±0.7 | 38.7±0.8 | +1.5 | 6 | 869 | 9 | 1304 | 18 | 2608 | 420 | 1.24 |
| 42.7-1.2 | |||||||||||
| 1-38-5 | 38±0.7 | 44.7±0.8 | +1.5 | 5 | 725 | 7.5 | 1087 | 15 | 2174 | 500 | 1.45 |
| 48.7-1.2 | |||||||||||
| 1-54-4 | 51±0.7 | 58.1±0.8 | +1.5 | 4 | 579 | 6 | 8694 | 12 | 1739 | 630 | 1.9 |
| 62.1-1.2 | |||||||||||
| 1-64-2.5 | 64±1 | 71.2±1 | 75.2±1.5 | 2.5 | 362 | 3.75 | 543 | 7.5 | 1087 | 770 | 2.4 |
| 1-76-1.5 | 76±1 | 83.8±1 | 87.8±1.5 | 1.5 | 217 | 2.25 | 326 | 4.5 | 652 | 930 | 2.95 |
| 1-89-1 | 89±1 | 96.8±1 | 100.8±1.5 | 1 | 144.9 | 1.5 | 217 | 3 | 435 | 1100 | 3.24 |
| 1-102-1 | 102±1 | 111±1 | 115±1.5 | 1 | 144.9 | 1.5 | 217 | 3 | 435 | 1250 | 3.85 |
| 1-127-1 | 127±1 | 136±1 | 141±1.5 | 1 | 144.9 | 1.5 | 217 | 3 | 435 | 1500 | 4.8 |
| 1-152-1 | 152±1 | 162±1 | 167±1.5 | 1 | 144.9 | 1.5 | 217 | 3 | 435 | 1800 | 5.8 |
| 1-203-1 | 203±1 | 214±1.5 | 220±2 | 1 | 144.9 | 1.5 | 217 | 3 | 435 | 8.8 | 8.8 |
