KEY PERFORMANCE
EN/DIN and new SAE rated working pressures
Approved at 1.000.000 fl exing impulse cycles Over standard pressure resistance Outstanding ozone and weather resistance biological and mineral oils compatibility
Appearance: Wrap
Branding: Printing and indelible branding with embossed technology
Colour: Black,red,blue, yellow, green, gray.
Continuous service temperature range: -40°f / +250°f, -40°c / +121°c
Max operating temperature: 257°f 125°c
Insert: Shf-type
Tube: Oil resistant synthetic rubber
Reinforcement: Four high tensile steel spirals (dn 19~31); six high tensile steel spirals (dn 38~51)
Cover: Environment resistant synthetic rubber
Applicable specs: EN 856 R13 - SAE 100 R13 - ISO 3862-1 R13
APPLICATIONS & FLUIDS
Hydraulics: Heavy duty power lines, hydrostatic transmissions
Mineral oils, vegetable oils and synthetic ester based oils, (up to 212°F 100°C), glycols and polyglycols,mineral oils in aqueous emulsion, water.
| Model no. | HOSE SIZE I.D | R.O.D | O.D | MAX W.P | MIN B.P | MIN B.R | W.T | ||||
| DN | dash | inch | mm | mm | bar | psi | bar | psi | mm | Kg/m | |
| WS R13 19 | 19 | -12 | 3/4" | 29.0 | 32.0 | 350 | 5076 | 1400 | 20305 | 240 | 1.62 |
| WS R13 25 | 25 | -16 | 1" | 36.0 | 39.2 | 350 | 5076 | 1400 | 20305 | 300 | 2.12 |
| WS R13 31 | 31 | -20 | 1.1/4" | 46.0 | 49.0 | 350 | 5076 | 1400 | 20305 | 420 | 4.01 |
| WS R13 38 | 38 | -24 | 1.1/2" | 54.6 | 57.8 | 350 | 5076 | 1400 | 20305 | 500 | 4.99 |
| WS R13 51 | 51 | -32 | 2" | 68.4 | 72.0 | 350 | 5076 | 1400 | 20305 | 630 | 7.33 |
Our factory:
≡ FAQ
Q: Do you produce smooth or cloth wrapped cover?
A: Yes, we can produce both cover, which depends on customer's request.
Q: Can you produce product with my own brand?
A: Yes, OEM or ODM is warmly welcome by our company. Hope we both parties will benefit a lot through the cooperation.
Q:Could we get free samples?
A: Yes. We can provide the free sample for you
Q: Does your product have different color hose?
A: Yes, we currently provide black, grey, red, blue and yellow.
Q:Could you crimp hose?
A: Yes, we can crimp hose assembly for our customers
Q: How long does my order take to be delivered?
A: It usually takes 5 to 30 days, which generally depends on the quantity of your order and our storage.
