Article and photos by Gregory Havel

When we think of concrete, we usually think of a mixture of gravel, sand, Portland cement, and water that is poured into forms and allowed to set and cure.

Another method of concrete placement is by “gunning,” which refers to pumping the concrete to a nozzle and using compressed air to blow it into place under pressure. This process can be used on floor slabs, walls, and overhead surfaces like ceilings and roofs.

There are two ways that concrete can be placed using this method:

This article will discuss the wet-mix method of shotcrete.

Among the advantages of shotcrete over poured concrete are:

The primary disadvantage of shotcrete compared to poured concrete is the amount of time that it takes when used for large foundations, structural piers, and other structures with large cross-sections, compared to using conventional forms for these large structures.

Two common problems when applying shotcrete are gravel in the concrete aggregate that is too large, which interferes with the spraying of the concrete; and ready-mixed concrete that is too wet (too great a slump), so that it does not stick well to vertical and overhead surfaces.

Concrete applied by shotcrete often incorporates steel reinforcing bars. Photo 1 shows the bottom and sides of the deep end of a large municipal swimming pool. The shotcrete crew is standing on the steel reinforcing for the bottom of the pool, which is supported by concrete masonry units resting on compacted soil. This steel reinforcement will be completely embedded in the concrete when the procedure is done, as it is at the rear of the photo near the top of the wall.

Photo 2 shows another view of the crew, with the nozzleman at the left, the hose-handlers in the center, and finishers with hand trowels at the far left. Also visible are the two hoses leading to the nozzle. The larger hose contains concrete and is connected to the concrete pump at the top of the embankment, near the ready-mix truck. The smaller hose is connected to a large, trailer-mounted air compressor, to supply the compressed air to blow the concrete into place.

Photo 3 is another view of the crew, with a better view of the concrete finishers on the right.

Photo 4 is a close-up of the shotcrete nozzle, with its connection to the hose from the concrete pump, and the compressed air valve and hose connection to the air compressor. By adjusting the compressed air valve, the nozzleman can control the velocity with which the concrete is discharged. The volume of concrete that is discharged is controlled at the concrete pump.

The shotcrete is usually hand-troweled in close quarters, as shown in the photos, and on walls and ceilings. On large, flat, open areas, like floors and the bottoms of swimming pools, the finishing may be done with troweling machines as with conventionally poured concrete.

On very large shotcrete jobs, the hoses and nozzle may be carried by a robotic boom operated by remote control.
