Products Description:
1.Size:6.5/7.5/8.0/8.5/10/13mm
2.W.P:40/50/60/80Bar
3.B.P:120/160/200/250Bar
4.Thickness:3mm
5.Color:Yellow,Red color etc.
6.Working Temperature:-10ºC to 70ºC
7.Package:50/100M/Roll
| item | code no | ID(mm) | W.P(BAR) | B.P(BAR) |
| 1PLY-3LAYER | SY65 | 6.50 | 40 | 120 |
| 1PLY-3LAYER | SY80 | 8.00 | 40 | 120 |
| 2PLY-5LAYER | SYF65 | 6.50 | 50 | 160 |
| 2PLY-5LAYER | SYF75 | 7.50 | 50 | 160 |
| 2PLY-5LAYER | SYF85 | 8.50 | 50 | 160 |
| 2PLY-5LAYER | SYF10 | 10.00 | 50 | 160 |
| 2PLY-5LAYER | SYF13 | 13.00 | 50 | 160 |
| WEAVE REINFORCED | SYB65 | 6.50 | 60 | 200 |
| WEAVE REINFORCED | SYB85 | 8.50 | 60 | 200 |
| WEAVE REINFORCED | SYB10 | 10.00 | 60 | 200 |
| WEAVE REINFORCED | SYB13 | 13.00 | 60 | 200 |
| WEAVE REINFORCED | SYB65-S | 6.50 | 80 | 250 |
| WEAVE REINFORCED | SYB85-S | 8.50 | 80 | 250 |
| WEAVE REINFORCED | SYB10-S | 10.00 | 80 | 250 |
| WEAVE REINFORCED | SYB13-S | 13.00 | 80 | 250 |
Products Features:
1.Made with high-qualtiy PVC and strong reinforced yarn
2. Strong peeling adhesion between yarn and inner-outer tube
3. Stable against kinking and twisting under work pressure
4. High resistance to corrosion,aging
5. Spraying agricultural chemicals,power sprayer,cleaning devices
Package Details:
Packaged: 100Meters/Roll,1Roll/CTN
Carton dimensions:45*14*45cm
N.W:12KGS G.W:14KGS
980CNTS/20GP Container
1970CNTS/40GP Container
2400CNTS/40HQ Container
Delivery Details:
20-25 days after receive the deposite
