Six Heavy Steel Wire Spiral Hydraulic Rubber Hose R15
Executive standard:SAE 100 R15
Construction:
Application:
Heavy duty impulsive high pressure hydraulic applications like excavators, dosers, dumpers, cranes, compactors, rock breakers and hydraulic drill rigs and other construction equipments. Suitable for petroleum based hydraulic fluids, synthetic esters, biodegradable hydraulic fluids, water-glycol based fluids and air.
Specification:
Following are pictures of Six Heavy Steel Wire Spiral Hydraulic Rubber Hose R15:
The pictures of package:
The pictures of our factory:
Our Main Product:
1. Hydraulic Hose
SAE 100R1AT/EN853 1SN
SAE 100R2AT/EN853 2SN
SAE 100R3
SAE 100R4
SAE 100R5
SAE 100R7/R8
SAE 100R9R
SAE 100R12/4SH/4SP
SAE 100R14/Teflon hose
SAE 100R13/R15
SAE 100R16
SAE 100R17
EN857 1SC
EN857 2SC
EN854 1TE
EN854 2TE
EN854 3TE
2. Oil/Water Delivery Rubber hose
3. Oil/Water Suction and Discharge hose
4. High Temperature Steam Hose
5. Welding hose (Oxygen/Acetylene hose)
6. Twin hose (Oxygen/Acetylene hose)
7. LPG hose
8. Air/Water Hose
Our Services
We can offer OEM Services.
We can provide FREE SAMPLE for our customers.
We can crimp hose assembly for our customers.
We welcome clients to visit our factory leading to better understanding of our production.
FAQ's
Q1. Do you produce smooth or cloth wrapped cover?
A. Both, we can produce both cover, which depends on customer's request.
Q2. Do you produce embossed marking?
A. Yes, we do provide embossed and printing markings with different color.
Q3. Can you produce product with my own brand?
A. Yes, we have been offering OEM services for more than 13 years.
Q4. Does your product have different color hose?
A. Yes, we currently provide black, grey, red, blue and yellow.
Q5. How long does my order take to be delivered?
A. It usually takes 5 to 30 days, which generally depends on the quantity of your order and our storage.
Our principle:
Excellent quality. Fast delivery. Integrity service.
For any inquiries,please contact us directly !
HAPPY (TIANJIN) TECHNOLOGY & DEVELOPMENT CO.,LTD
Abby.Wu
TEL:022-60777677
Mobilephone:+86 13920207623
Executive standard:SAE 100 R15
Construction:
- Tube:Oil resistant synthetic rubber.
- Reinforcement:Six tensile steel wire spiral layers. (DN32/38/51)
- Cover:Black, abrasion and weather resistant synthetic rubber.
- Temperature range: -40° C to +121° C
Application:
Heavy duty impulsive high pressure hydraulic applications like excavators, dosers, dumpers, cranes, compactors, rock breakers and hydraulic drill rigs and other construction equipments. Suitable for petroleum based hydraulic fluids, synthetic esters, biodegradable hydraulic fluids, water-glycol based fluids and air.
Specification:
| DN | Hose I.D | Hose O.D | Working Pressure | Burst Pressure | Minimum Bend Radius | Weight | |
| inch | mm | mm | MPa | MPa | mm | kg/m | |
| 10 | 3/8 | 9.3 | 23.3 | 42 | 168 | 153 | 0.80 |
| 12.5 | 1/2 | 12.3 | 26.8 | 42 | 168 | 203 | 0.95 |
| 19 | 3/4 | 18.6 | 36.1 | 42 | 168 | 267 | 1.85 |
| 25 | 1 | 25.0 | 42.9 | 42 | 168 | 330 | 2.90 |
| 31.5 | 1-1/4 | 31.4 | 51.5 | 42 | 168 | 445 | 4.20 |
| 38 | 1-1/2 | 37.7 | 59.6 | 42 | 168 | 533 | 5.60 |
Following are pictures of Six Heavy Steel Wire Spiral Hydraulic Rubber Hose R15:
The pictures of package:
The pictures of our factory:
Our Main Product:
1. Hydraulic Hose
SAE 100R1AT/EN853 1SN
SAE 100R2AT/EN853 2SN
SAE 100R3
SAE 100R4
SAE 100R5
SAE 100R7/R8
SAE 100R9R
SAE 100R12/4SH/4SP
SAE 100R14/Teflon hose
SAE 100R13/R15
SAE 100R16
SAE 100R17
EN857 1SC
EN857 2SC
EN854 1TE
EN854 2TE
EN854 3TE
2. Oil/Water Delivery Rubber hose
3. Oil/Water Suction and Discharge hose
4. High Temperature Steam Hose
5. Welding hose (Oxygen/Acetylene hose)
6. Twin hose (Oxygen/Acetylene hose)
7. LPG hose
8. Air/Water Hose
Our Services
We can offer OEM Services.
We can provide FREE SAMPLE for our customers.
We can crimp hose assembly for our customers.
We welcome clients to visit our factory leading to better understanding of our production.
FAQ's
Q1. Do you produce smooth or cloth wrapped cover?
A. Both, we can produce both cover, which depends on customer's request.
Q2. Do you produce embossed marking?
A. Yes, we do provide embossed and printing markings with different color.
Q3. Can you produce product with my own brand?
A. Yes, we have been offering OEM services for more than 13 years.
Q4. Does your product have different color hose?
A. Yes, we currently provide black, grey, red, blue and yellow.
Q5. How long does my order take to be delivered?
A. It usually takes 5 to 30 days, which generally depends on the quantity of your order and our storage.
Our principle:
Excellent quality. Fast delivery. Integrity service.
For any inquiries,please contact us directly !
